Look to thy mouth; diseases enter here.
George Herbert (1593-1632)
General Considerations
The mouth and oral cavity are used by individuals to express the entire range of emotions. As early as infancy, the mouth provides gratification and sensory pleasure.
Approximately 20% of all visits to primary care physicians are related to problems of the oral cavity and throat. Most patients with these problems present with throat pain, which may be acute and associated with fever or difficulty in swallowing. A sore throat may be the result of local disease, or it may be an early manifestation of a systemic problem.
It has been estimated that more than 90% of patients infected with human immunodeficiency virus (HIV) have at least one oral manifestation of the disease. It appears that as further immunologic impairment develops, the risk of oral lesions increases. There are several important oral manifestations that are strongly associated with early HIV infection. The presence of any of them mandates HIV testing.
Oral cancer represents about 3% of all cancers. Cancer of the oral cavity and pharynx was responsible for 7550 deaths in 2007, killing approximately 1 person per hour, 24 hours per day. The rate of death from oral cancer is higher than those from cervical cancer; Hodgkin's disease; cancer of the brain, liver, testis, kidney, or ovary; or malignant melanoma. One of the reasons for this high death rate is that the cancer is routinely discovered late in its development, with metastases to other areas or invasion deep into local structures. Oral cancer is also particularly dangerous because it has a high risk of producing second primary tumors. This means that patients who survive a first encounter with the disease have up to a 20 times higher risk for development of a second cancer. There is a 2:1 male-to-female incidence ratio and a 2:1 African-American-to-white death rate ratio. It is estimated that a man has a 1:72 lifetime risk for development of oral cancer. The American Cancer Society estimates that approximately 34,360 new cases of oral cancer were diagnosed in 2007 in the United States, with 24,180 cases occurring in men and 10,180 in women. Worldwide, the problem is much greater: More than 350,000 to 400,000 new cases are diagnosed each year. Although the exact cause of tongue cancer remains unknown, it most often occurs in people who use tobacco products (cigarettes, cigars, pipes, and smokeless tobacco), consume alcohol (especially when combined with tobacco use), or chew betel nuts. Chewing of betel nuts is not a common practice in the United States, but it is a widespread habit in many parts of the world, especially in Taiwan (see Fig. 12-51).
Many physician visits for oral problems are associated with psychiatric disturbances. Psychosomatic disease symptoms often center on the mouth. Patients with psychosomatic disease may complain of ''burning'' or ''dryness'' of the mouth or tongue. Bruxism, or grinding of the teeth other than for chewing, occurs especially during sleep. This overuse of the muscles of mastication has often been interpreted as a manifestation of rage or aggression that is not overtly displayed; it may also be an infantile response to reduce psychic tension. Bruxism can produce facial pain, which causes further spasm of the muscles and continued bruxism, resulting in a vicious circle. Individuals who habitually have something in their mouths, such as a pipe, a thumb, or a pencil, may cause damage to their oral cavities.
Figure 12-1 The oral cavity.
Although it is often thought that the oral cavity is examined only by dentists, other healthcare professionals must have competency in evaluating this important region of the body. The health-care provider must be able to accomplish the following:
1. Appraise oral hygiene
2. Recognize dental caries and periodontal disease
3. Recognize the presence of oral lesions, as well as disorders of the regional lymph nodes, salivary glands, and bony structures
4. Recognize oral manifestations of systemic disease
5. Recognize systemic problems caused by oral disease and procedures
6. Assess physical findings concerning the range and smoothness of jaw motion
7. Identify dental appliances
8. Know when a dental consultation is required or should be postponed because of a medical problem
Structure and Physiology
The Oral Cavity
• The oral cavity consists of the following structures:
• Buccal mucosa
• Lips Tongue
• Hard and soft palates Teeth
• Salivary glands
The oral cavity extends from the inner surface of the teeth to the oral pharynx. The hard and soft palates form the roof of the mouth. The soft palate terminates posteriorly at the uvula. The tongue lies at the floor of the mouth. At the most posterior aspect of the oral cavity lie the tonsils, between the anterior and posterior pillars. The oral cavity is illustrated in Figure 12-1.
Figure 12-2 The tongue viewed from above.
The buccal mucosa is a mucous membrane that is continuous with the gingivae and lines the insides of the cheeks. The linea alba, or bite line, is a pale or white line along the line of dental occlusion. It may be slightly raised and show impressions of the teeth.
Lips are red as a result of the increased number of vascular dermal papillae and the thinness of the epidermis in this area. An increase in desaturated hemoglobin, cyanosis, is manifested as blue lips. The common blue discoloration of the lips in a cold environment is related to the decreased blood supply and increased extraction of oxygen.
The tongue lies at the floor of the mouth and is attached to the hyoid bone. It is the main organ of taste, aids in speech, and serves an important function in mastication. The body of the tongue contains intrinsic and extrinsic muscles and contains the strongest muscle of the body. The tongue is supplied by the hypoglossal, or 12th cranial, nerve.
The dorsum of the tongue has a convex surface with a median sulcus. Figure 12-2 shows the tongue viewed from above. At the posterior portion of the sulcus is the foramen cecum, which marks the area of the origin of the thyroid gland. Behind the foramen cecum are mucin-secreting glands and an aggregate of lymphatic tissue called the lingual tonsils. The texture of the tongue is rough as a result of the presence of papillae, the largest of which are the circumvallate papillae (Fig. 12-3). There are approximately 10 of these round papillae, which are located just in front of the foramen cecum and divide the tongue into the anterior two thirds and the posterior one third. Filiform papillae are the most common papillae and are present over the surface of the anterior portion of the tongue. The fungiform papillae are located at the tip and sides of the tongue. These papillae can be recognized from their red color and broad surface.
The taste buds are located on the sides of the circumvallate and fungiform papillae. Taste is perceived from the anterior two thirds of the tongue by the chorda tympani nerve, a division of the facial nerve. The glossopharyngeal, or ninth cranial, nerve perceives taste sensation from the posterior third of the tongue. There are four basic taste sensations: sweet, salty, sour, and bitter. Sweetness is detected at the tip of the tongue. Saltiness is sensed at the lateral margins of the tongue. Sourness and bitterness are perceived at the posterior aspect of the tongue and are carried by the glossopharyngeal nerve.
Figure 12-3 Circumvallate papillae.
Figure 12-4 Palatal rugae.
When the tongue is elevated, a mucosal attachment, the frenulum, may be seen underneath the tongue in the midline connecting the tongue to the floor of the mouth.
The hard palate is a concave bone structure. The anterior portion has raised folds, or rugae. Figure 12-4 shows the palatal rugae. The soft palate is a muscular, flexible area posterior to the hard palate. The posterior margin ends at the uvula. The uvula aids in closing off the nasopharynx during swallowing.
Teeth are composed of several tissues: enamel, dentin, pulp, and cementum. Enamel covers the tooth and is the most highly calcified tissue in the body. The bulk of the tooth is the dentin. Under the dentin is the pulp, which contains branches of the trigeminal, or fifth cranial, nerve and blood vessels. The cementum covers the root of the tooth and attaches it to the bone. Figure 12-5 shows a cross section through a molar tooth.
The primary dentition, or the deciduous teeth, consists of 20 teeth that erupt from the ages of 6 to 30 months. The primary dentition per quadrant of jaw consists of two incisors, one canine, and two premolars. These teeth are shed from the ages of 6 to 13 years. The secondary dentition, or the permanent teeth, consists of 32 teeth that erupt from the ages of 6 to 22 years. The secondary dentition per quadrant of jaw consists of two incisors, one canine, two premolars, and three molars. Figure 12-6 illustrates the primary and secondary dentition, and Table 24-5 summarizes the chronology of dentition.
Although not part of the oral cavity proper, the salivary glands are considered part of the mouth. There are three major salivary glands: the parotid, the submandibular, and the sublingual glands. The parotid gland is the largest of the salivary glands. It lies anterior to the ear on the side of the face. The facial, or seventh cranial, nerve courses through the gland. The duct of the parotid gland, Stensen's duct, enters the oral cavity through a small papilla opposite the upper first or second molar tooth. The submandibular gland is the second largest salivary gland. It is located below and in front of the angle of the mandible. The duct of the submandibular gland, Wharton's duct, terminates in a papilla on either side of the frenulum at the base of the tongue. The sublingual gland is the smallest of the major salivary glands. It is located in the floor of the mouth, beneath the tongue. There are numerous ducts of the sublingual gland, some of which open into Wharton's duct. In addition to these major salivary glands, there are hundreds of very small salivary glands located throughout the oral cavity.
Figure 12-5 Cross-sectional view through a molar tooth.
Figure 12-6 Primary dentition (left) and secondary dentition (right).
The Pharynx
The pharynx is divided into the nasopharynx, the oropharynx, and the hypopharynx. The nasopharynx lies above the soft palate and is posterior to the nasal cavities. On its posterolateral wall is the opening of the eustachian tube. The adenoids are pharyngeal tonsils and hang from the posterosuperior wall near the opening of the eustachian tube. The oropharynx lies below the soft palate, behind the mouth, and superior to the hyoid bone. Posteriorly, it is bounded by the superior constrictor muscle and the cervical vertebrae. Below the oropharynx is the area known as the hypopharynx (or laryngopharynx). The hypopharynx is surrounded by three constrictor muscles, which are innervated by the glossopharyngeal and vagus nerves. The hypopharynx ends at the level of the cricoid cartilage, where it communicates with the esophagus through the upper esophageal sphincter. Figure 12-7 illustrates the functional parts of the pharynx.
The muscular walls of the pharynx are formed by the constrictor muscles, which function during the act of swallowing. The blood supply is derived from the external carotid artery.
Lymphatic tissue is abundant in the pharynx. The lymphoid tissue consists of the palatine tonsils, the adenoids, and the lingual tonsils. These tissues form Waldeyer's ring. The palatine tonsils lie in the tonsillar fossa, between the anterior and posterior pillars. The palatine tonsils are almond-shaped and vary considerably in size. The adenoids lie on the posterior wall of the nasopharynx, and the lingual tonsils are located at the base of the tongue. The upper portion of the pharynx drains to the retropharyngeal nodes, and the lower part drains to the deep cervical lymph nodes.
Figure 12-7 Functional parts of the pharynx.
The functions of the pharynx are as follows:
• Enable swallowing
• Enable speech
• Provide an airway
Swallowing, or deglutition, is divided into three stages. The voluntary stage occurs when a bolus of food is forced by the tongue past the tonsils to the posterior pharyngeal wall. The second stage is involuntary constriction by the pharyngeal muscles, propelling the bolus from the pharynx to the esophagus. The third stage is also involuntary, in which the esophageal muscles push the bolus down into the stomach. The larynx is first raised and then closed during the first two stages of swallowing. The eustachian tubes open during swallowing when the nasopharynx closes.
The pharynx also acts as a structure of resonation and articulation. Resonation refers to the vibration of a structure. Articulation is the change in shape of a structure to produce speech. Contracting the pharyngeal muscles causes a change in the acoustic quality of speech. Changes in the size and shape of the pharynx affect resonance. The soft palate affects resonance by opening and closing the partition between the oral and nasal cavities. If closure is incomplete, nasal speech results.
The Larynx
The larynx is located at the superior margin of the trachea and below the hyoid bone, which is located at the base of the tongue. The larynx is at the level of the fourth to sixth cervical vertebrae. The larynx functions as a guard against the entrance of solids and liquids into the trachea, as well as being the organ of voice production.
The epiglottis is attached above the larynx. The function of the epiglottis is generally believed to be protection of the airway during swallowing.
The body of the larynx consists of a series of cartilaginous structures: the thyroid, the cricoid, and the arytenoid cartilages. The thyroid cartilage forms the bulk of the structure of the larynx and produces the prominence in the neck known as the Adam's apple. Toward the top of the thyroid cartilage is the thyroid notch. Farther down on the thyroid cartilage, there is a space, the cricothyroid space and membrane, that separates the thyroid cartilage from the cricoid cartilage.
Figure 12-8 Laryngeal cartilages.
The cricoid cartilage articulates with the cricothyroid membrane superiorly and the trachea interiorly. It is the only complete ring of cartilage in the larynx. The paired arytenoid cartilages provide an important area for attachment of the vocal cords. A diagram of the thyroid and cricoid cartilages onto the neck is illustrated in Figure 12-8, and the laryngeal skeleton is illustrated in Figure 12-9.
The vocal cords vibrate to generate speech. Sound is produced by the rapid vibration of the vocal cords excited by the exhaled stream of air. The vocal cords are brought together, and their tension is changed, by the action of various laryngeal muscles. The nerve supply to the larynx is derived from the superior and recurrent laryngeal branches of the vagus, or 10th cranial, nerve. Voice produced at the larynx is modified by the pharynx and oronasal cavity.
Review of Specific Symptoms
The Oral Cavity
All patients should be asked the following:
''When did you last see a dentist? What did the dentist do?''
Figure 12-9 Laryngeal skeleton.
''Do your gums bleed?''
''Have you any pain, sores, or masses on your lips or in your mouth that do not heal?''
''Have you had any problems after extraction of a tooth?''
(If the patient wears dentures) ''Have you noticed any change in the way your dentures fit?''
Cancers of the oral cavity are most often found in people who are older than 45 years of age. Cancer of the lip is more common in men than in women and is more likely to develop in people with light-colored skin who have spent extensive time in the sun. Cancer of the oral cavity is more common in people who chew tobacco or smoke pipes. A possible sign of a cancer of the mouth or gums is when dentures no longer fit well.
The most important symptoms of disease of the oral cavity are as follows:
• Pain Ulceration Bleeding
• Mass
• Halitosis (bad breath)
• Xerostomia (dry mouth)
Pain
When a patient complains of oral pain, it is important to ask the following:
‘‘Where is the pain?''
''Describe the pain.''
‘‘Do you feel the pain anywhere else?''
‘‘How long has the pain been present?''
‘‘What brings the pain on?''
''What makes it better? worse?''
‘‘When you have the pain, do you have any other symptoms?''
Tooth pain may be a symptom of underlying gingival disease. A history of dental procedures and recent dental work should be documented.
Pain in the teeth may sometimes be referred from the chest. Patients with angina may actually complain of pain in their teeth associated with exertion. Careful and thoughtful questioning is indicated.
Ulceration
Oral ulcerative lesions are common and may be manifestations of local or systemic disease of immunogenic, infectious, malignant, or traumatic origin. The patient's history is important because it indicates whether the lesions are acute or chronic, single or multiple, and primary or recurrent.
Oral pain is frequently related to ulceration of the lips or tongue. Cancer is not the most common cause of oral cavity ulceration, but it must always be considered. When a patient complains of ulceration, ask the following questions:
‘‘Have you had a lesion like this before?''
''Are there multiple lesions?''
How long have the lesions been present?''
''Are there lesions anywhere else on the body, such as in the vagina? In the urethra? In the anus?'' Are the lesions painful?''
Do you smoke?'' If so, How much?''
Do you drink alcohol?''
''Do you have a history of venereal disease?''
The examiner should ask about a patient's sexual habits. These questions were discussed in Chapter 1, The Interviewer's Questions. Smoking and drinking alcohol predispose an individual to precancerous lesions of the mouth, such as leukoplakia and erythroplakia.
Bleeding
Bleeding may result from a primary hematologic disorder or from a local inflammation or neoplasm. Many medications may also cause or predispose a patient to bleeding. Always ask whether the patient is taking any medications.
Mass
If a patient complains of, or on physical examination is found to have, an intraoral mass or a mass in the region of a salivary gland, determine its duration and whether the mass is painful. A painless mass is usually a sign of a tumor.
Are there associated symptoms such as excessive salivation, known as ptyalism, or dryness of the mouth, known as xerostomia? Is dysphagia (difficulty in swallowing) present?
Halitosis
Halitosis affects about 50% of all adults. Fortunately, in only a small percentage does the problem persist the entire day. Most individuals with halitosis are told by others that they have bad breath, although they themselves may be unaware of the problem. In some cases, the odor in the mouth is so objectionable that it can compromise the patient's social and professional life.
The source of bad breath is in the oral cavity in 90% of cases; the other 10% have disorders in the nasal passages or lungs or a systemic disease. It is questionable whether the gastrointestinal tract is a source of halitosis.
It is believed that halitosis is caused by volatile sulfur and other compounds exhaled into the air during speech and respiration. These compounds are produced by putrefactive, gramnegative anaerobic bacteria colonizing on the posterior dorsum of the tongue, in periodontal pockets, and around some dental restorations and prostheses. The volatile sulfur compounds are generated by the bacterial metabolism of sulfur-containing amino acids. Xerostomia increases the level of volatile sulfur compounds.
Patients with systemic diseases such as diabetes mellitus, cirrhosis, uremia, and cancer; infections of the perioral regions; and trimethylaminuria (fish odor syndrome) can suffer from bad breath. These conditions must be considered in the absence of oral and sinonasal disease.
Treatment of halitosis should be directed toward the underlying cause. Once it has been determined that the source of the bad breath is the oral region, the patient should be instructed in procedures of good oral hygiene, including proper tooth brushing, flossing, and, most important, cleaning of the posterior dorsum of the tongue with a special scraping device or toothbrush. Appropriate mouthwash may also be used. These procedures must be performed at least twice a day to remove the bacteria and accumulated metabolic products.
Xerostomia
Xerostomia, or dry mouth, is a common symptom of reduced or absent salivary secretion. It is most common in women and in aging populations. It is frequently observed as a side effect of various medications, including antihistamines, decongestants, tricyclic antidepressants, antihypertensives, and various anticholinergic medications. It may also occur with mouth breathing, neurologic disorders, radiation therapy to the head and neck, HIV infection, and autoimmune disorders. The saliva is thick, and the oral mucosal surfaces are dry; the tongue is commonly fissured and atrophic. The dry environment predisposes to candidiasis and dental caries.
The Pharynx
The most common symptoms of disease of the pharynx include the following:
• Nasal obstruction
• Pain
• Dysphagia
• Deafness
• Snoring
Nasal Obstruction
Nasal obstruction can result from enlarged adenoids or from tumor formation in the nasopharynx. It is important to determine whether the patient has any allergies or sinus trouble or has sustained nasal trauma.
Pain
Pain can result from inflammation of the tonsils or posterior pharynx, as well as from a tumor in this area. Acute throat pain may be caused by inflammatory processes or injury. A foreign body in the pharynx often produces severe pain that is worsened by swallowing. Often, throat pain may be referred to the ipsilateral ear. Chronic throat pain may be caused by inflammatory processes, as well as by neoplasms. Enlarged thyroid lobes or diffuse thyroid enlargement may cause throat pain associated with dysphagia. Hysteria is another cause of chronic throat pain.
Dysphagia
Dysphagia is difficulty in swallowing. Determine the site of obstruction. Does the dysphagia occur with liquids, solids, or tablets? Questions related to tonsillar infections are relevant because enlarged tonsils may interfere with swallowing. It is prudent to ask whether regurgitation of food occurs; this results from an abnormal pharyngeal pouch. The patient may say that the ''food gets stuck.'' This is often associated with significant disease.
Deafness
A tumor at the distal end of the eustachian tube in the nasopharynx can produce conductive deafness. Benign masses such as hypertrophied adenoids may be responsible. Nasopharyngeal malignancies may also be the cause of conductive deafness. In many cases, serous effusions in the middle ear space cause eustachian tube dysfunction.
Snoring
Snoring is a common complaint. An important problem often associated with heavy snoring is obstructive sleep apnea. Many affected patients are overweight and have a history of excessive daytime sleepiness. A bed partner may describe the patient as at first sleeping quietly; then a transition occurs to louder snoring, followed by a period of cessation of snoring, during which time the patient becomes restless, has gasping motions, and appears to be struggling for breath. This period is terminated by a loud snort, and the sequence may begin again. It is common for patients with sleep apnea to have many of these episodes each night.
The Larynx
Dysphonia
The major symptom of laryngeal disease is a change in the voice, especially the development of dysphonia, or hoarseness. Ask the following questions:
How long have you had the hoarseness?''
What seems to make it better? worse?''
‘‘Is there any time of day when it is worse?''
Have you had any surgery necessitating general anesthesia?''
''Have you had any injury to your neck?''
Determine whether the patient is or was a smoker. Recent onset of hoarseness may result from impingement on the recurrent laryngeal nerve as it hooks around the left bronchus. This may be caused by a tumor or by an enlarged left atrium. Voice overuse or vocal cord neoplasms are other causes of hoarseness. Procedures involving general anesthesia necessitate the use of an endotracheal tube, which could potentially damage a vocal cord and cause hoarseness.
Impact of a Voice Disorder on the Patient
Phonation is the process of sound production by the interaction of airflow through the glottis and the opening and closing of the vocal cords of the larynx. Voice loudness is proportional to
the air pressure below the glottis; pitch is related to this pressure and to the length of the vocal cords. Voice quality may change when there is interference with the vocal cords or pharyngeal cavity vibration (i.e., resonance).
A voice disorder may be related to an enlarged vocal cord, a laryngeal mass, or a neurologic or psychologic problem. A voice disorder is defined as the presence of a voice that is different in pitch, quality, loudness, or flexibility in comparison with the voices of other persons of similar age, sex, and ethnic group. An abnormal voice may be a symptom or sign of illness, and its cause should be determined.
In a study of a school-aged population, voice disorders were found in up to 23% of children. Most of these disorders were related to voice abuse and not to organic problems. In another study, 7% of men and 5% of women from 18 to 82 years of age were found to have voice disorders. Most of these disorders were related to organic problems.
Many patients with organic speech disorders are rejected by other people. Their speech may be high-pitched or nasal and a cause of embarrassment. Their self-esteem is low. They are rejected by others because their voice patterns are objectionable.
Just as a voice disorder has an impact on a person, a person can use his or her voice to have an impact on others. The manner in which a person speaks—the quality, pitch, loudness, stress patterns, rate—reflects his or her personality. Psychogenic voice disorders are functional disorders that are manifestations of psychologic imbalance. Voice is a useful indicator of affective disorders, such as depression, manic states, and mood swings, as well as of schizophrenia.
Physical Examination
The equipment necessary for the examination of the oral cavity consists of a penlight, gauze pads, gloves, applicator sticks, and tongue depressors.
The Oral Cavity
The physical examination of the oral cavity includes inspection and palpation of the following structures:
• Lips
• Buccal mucosa
• Gingivae Teeth Tongue
• Floor of the mouth
• Hard and soft palates
• Salivary glands
• Twelfth cranial nerve
Sit or stand directly in front of the patient, who should be seated. The patient's face should be well illuminated. Work systematically from front to back so that no areas are omitted. Put on a pair of gloves when palpating any structure in the mouth. When any lesion is found, note its consistency and tenderness. If the patient is wearing dentures, ask him or her to remove them. Inspect the face and mouth for asymmetries and abnormalities.
Evaluate the patient's breath. Is there any distinctive odor to the patient's breath? This may suggest poor oral hygiene or systemic disease. A fetid odor may be caused by extensive caries or periodontal disease.
Have the patient open his or her mouth If the mouth can be opened much beyond 35 mm, subluxation of the jaw may be present. Deviation of the jaw is suggestive of a neuromuscular or temporomandibular joint problem.
Inspect the Lips
Inspect the lips for localized or generalized swellings, and assess the patient's ability to open the mouth.
Assess the color of the lips. Is cyanosis present? Are there any lesions on the lips? If a lesion is detected, palpate it to characterize its texture and consistency. Figure 12-10 depicts the mouth of a patient with multiple herpetic ulcers, commonly known as cold sores, or herpes simplex labialis, on the lips and external nares. Figure 12-11 depicts multiple telangiectatic lesions on the tongue that are secondary to Osler-Weber-Rendu syndrome. In this syndrome, multiple telangiectases are present throughout the gastrointestinal tract. These may bleed insidiously, causing anemia. Figure 12-12 depicts the classic brown pigmentary changes on the lips of a patient with Peutz-Jeghers syndrome. This is an autosomal dominant disorder that is characterized by generalized gastrointestinal hamartomatous polyposis and mucocutaneous pigmentation.
Figure 12-10 Herpes simplex labialis.
A mucocele of the lip is a common bluish, cystic-appearing, painless, translucent, traumatically induced lesion. Mucoceles, which occur mostly on the lower lip, range in size from several millimeters to several centimeters and arise from obstruction or rupture of the minor salivary gland. When ruptured, a mucocele releases a clear, thick fluid. Figure 12-13 depicts a mucocele of the lower lip.
Inspect the Buccal Mucosa
The patient should be asked to open the mouth widely. The mouth should be illuminated with a light source. The buccal mucosa must be evaluated for any lesions or color changes, and the buccal cavity is inspected for any evidence of asymmetry or areas of injection (dilated vessels, usually indicative of inflammation). The buccal mucosa, teeth, and gingivae are easily evaluated by using a tongue depressor to retract the cheek away from the gums, as shown in Figure 12-14. The examiner should inspect for discolorations, evidence of trauma, and the condition of the parotid duct orifice.
Are there any ulcerations of the buccal mucosa? Are there white lesions on the buccal mucosa? A common painless white lesion in the mouth is lichen planus, which appears as a reticulated, or lacelike, eruption bilaterally on the buccal mucosa. An erosive, painful variant is similar in appearance except for the presence of hemorrhagic and ulcerated lesions. Nonerosive lichen planus is shown in Figure 12-15. Is leukoplakia present? In the mouth, leukoplakia can manifest as a painless, precancerous white plaque on the cheeks, gingivae, and tongue. Leukoplakia of the gingiva is pictured in Figure 12-16. Over 15 years, this lesion developed into verrucous hyperplasia, verrucous carcinoma, and finally squamous cell carcinoma. A resection of the maxilla and palate was required. Figure 12-17 depicts leukoplakia of the tongue in another patient. The thick, white, adherent patches are sharply demarcated and cannot be denuded from the tongue.
Figure 12-11 Osler-Weber- Rendu syndrome. Note the telangiectatic lesions.
Figure 12-12 Peutz-Jeghers syndrome. Note the pigmentary changes.
Figure 12-13 Mucocele of the lower lip.
Figure 12-14 Inspection of the mouth.
Figure 12-15 Nonerosive lichen planus of the buccal mucosa.
Figure 12-16 Leukoplakia of the gingiva.
Figure 12-17 Leukoplakia of the tongue.
Small, pinhead-sized, yellow papules on the buccal mucous membrane are usually Fordyce's spots or granules. Fordyce's spots are normal, prominent, ectopic sebaceous glands commonly seen on the lips or buccal mucosa near the exit of the parotid duct and are probably the most common lesions in the mouth. Figure 12-18 depicts Fordyce's spots on the buccal mucosa. Ectopic sebaceous glands can also be found on the shaft of the penis (see Fig. 18-11) and on the labia (see Fig. 19-13).
Figure 12-19 shows angiokeratomas of the buccal mucosa, or angiokeratoma corporis diffusum, in a patient with Fabry's disease. Figure 18-18 depicts angiokeratomas on the scrotum of the same patient.
Inspect the Gingivae
Normal gingivae are stippled, pink, and firm. Does the gingival tissue completely occupy the interdental space? Are the roots of the teeth visible, indicating recession of the periodontal tissue? Is there pus or blood along the gingival margin? Are the gingivae swollen? Is there evidence of bleeding? Is gingival inflammation present? Is abnormal coloration present? Erythroplakia is an area of mucous membrane on which there are granular, erythematous papules that bleed. Erythroplakia has a greater potential for malignancy than does leukoplakia. Figure 12-20 shows the mouth of a patient with erythroplakia of the gingiva (on the right) and inflammatory gingivitis (on the left).
Figure 12-18 Fordyce's spots (granules) on the buccal mucosa.
Figure 12-19 Angiokeratomas of the buccal mucosa.
Figure 12-20 Erythroplakia of the gingiva (right).
There are many causes of gingival hyperplasia, including heredity, hormonal imbalances of puberty and pregnancy, medications, and leukemia. Gingival hyperplasia is common in patients taking phenytoin (Dilantin), an antiepilepsy medication, and in those taking nifedipine, a calcium channel blocker. It has been estimated that gingival hyperplasia develops in 30% to 50% of all patients taking phenytoin. The hyperplastic gingival changes of hormonal imbalances usually recede once the hormones have returned to their normal, lower levels. Figure 12-21 depicts marked gingival hyperplasia in a patient who was taking phenytoin. Dense leukemic infiltration of the gingiva is commonly seen in acute monocytic and acute monomyelocytic leukemia. Figure 12-22 shows gingival enlargement and bleeding caused by acute monomyelocytic leukemic infiltration.
Inspect the Teeth
There are 32 teeth in the full adult dentition. Is the dentition appropriate for the patient's age? The teeth should be inspected for caries and malocclusion. Are the teeth clean, especially around the gum line? Is there discoloration of the teeth? Is there tooth loss? Inspection of the teeth often provides insight into the patient's attitude toward general hygiene.
Are the teeth aligned properly? Ask the patient to bite normally while you retract the buccal mucosa with a tongue depressor. How many teeth bear force on mastication? Repeat this inspection on the other side. Do the maxillary teeth overlap the mandibular ones, and are they in contact with them? If so, the bite is probably normal.
If the patient is wearing dental appliances such as dentures or bridges, he or she should remove them for a complete evaluation.
Figure 12-21 Gingival hypertrophy in a patient taking phenytoin (Dilantin).
Figure 12-22 Gingival hypertrophy in a patient with acute monomyelocytic leukemia. Note the bleeding gingivae.
Inspect the Tongue
Inspect the mucosa, and note any masses or ulceration. Is the tongue moist? Ask the patient to stick out the tongue. A neuromuscular weakness may be present if the tongue cannot protrude in the midline or move rapidly in all directions. Are there any mass lesions on the sides or undersurface of the tongue? Ask the patient to lift the tongue to the roof of the mouth so that the inferior aspect of the tongue can be inspected. In older individuals, the large veins on the ventral aspect of the tongue may be tortuous. These varicosities never bleed spontaneously and have no clinical significance. Figure 12-23 shows a patient with sublingual varices. Figure 12-24 shows a patient with a benign lipoma of the tongue.
A geographic tongue is a benign condition in which the dorsum of the tongue has smooth, localized red areas, denuded of filiform papillae, surrounded by well-defined, raised yellowish- white margins and normal filiform papillae. These areas together give the tongue a maplike appearance. The appearance of the tongue gradually changes as the depapillated areas heal and new areas of depapillation occur. A black hairy tongue is another benign condition in which the filiform papillae on the dorsum of the tongue are greatly elongated; these enlarged, ''hairy'' papillae become pigmented with a brownish black color caused by staining from food or tobacco or proliferating chromogenic microorganisms. This condition, more commonly seen in men, may be a sequela to antibiotic therapy. A scrotal, or fissured, tongue is another normal variant; approximately 5% of the population has fissures in the tongue. The fissures first develop in late childhood and become deeper with age. The fissure pattern is quite variable. Food debris may collect in the fissures, causing inflammation, but the condition is otherwise benign. Halitosis may be a problem. Figure 12-25 shows these three normal tongue variants.
Figure 12-23 Sublingual varices of the tongue.
Figure 12-24 Benign lipoma of the tongue.
Is candidiasis present? Candidiasis, also known as moniliasis or thrush, is an opportunistic mycotic infection. It frequently involves the oral cavity, gastrointestinal tract, perineum, or vagina. The lesions appear as white, loosely adherent membranes, beneath which the mucosa is fiery red. Oral candidiasis is the most common cause of white lesions in the mouth. It is uncommon in healthy individuals who have not been receiving broad-spectrum antibiotic or steroid-based therapies. The presence of thrush in such a patient may be an initial manifestation of acquired immunodeficiency syndrome (AIDS). Candidiasis is the most common oral infection in patients with AIDS. The tongue of a patient with AIDS and oral candidiasis is pictured in Figure 12-26.
Is leukoplakia present? One form of leukoplakia, termed oral hairy leukoplakia, is associated with the subsequent development of AIDS. These raised white lesions appear corrugated, or ''hairy,'' and range in size from a few millimeters to 2 to 3 cm. They are most commonly found on the lateral margins of the tongue but may also be seen on the buccal mucosa. In the absence of other causes of immunosuppression, oral hairy leukoplakia is diagnostic of HIV infection. It is seen in more than 40% of patients with HIV infection. The tongue of a patient with AIDS with oral hairy leukoplakia is pictured in Figure 12-27.
Look for indurated ulcers or masses in the middle, lateral aspect of the tongue. This is the most common site for intraoral squamous cell carcinoma. Figure 12-28 depicts squamous cell carcinoma of the tongue in the classic location.
Figure 12-25 Three normal tongue variants. A, Geographic tongue. B, Black hairy tongue. C, Scrotal, or fissured, tongue.
Figure 12-26 Oral candidiasis.
Figure 12-27 Oral hairy leukoplakia.
Figure 12-28 Squamous cell carcinoma of the tongue.
Figure 12-29 Palpation of the tongue.
Palpate the Tongue
After a thorough inspection of the tongue, the examination proceeds with palpation. The patient sticks out the tongue onto a piece of gauze. The tongue is then held by the examiner's right hand as the sides of the tongue are inspected and palpated with the left hand. This is illustrated in Figure 12-29. To examine the other side of the tongue, the examiner reverses hands.
The anterior two thirds and the lateral margins of the tongue can be evaluated without stimulating the gag reflex. The examiner should palpate the lateral margins of the tongue because more than 85% of all lingual cancers arise in this area. All white lesions should be palpated. Is there evidence of induration (hardness)? Induration or ulceration is strongly suggestive of carcinoma. After the tongue is palpated, it is unwrapped, and the gauze is discarded. Any intraoral lesion, ulcer, or mass present for more than 2 weeks should be examined through biopsy and evaluated by an oral pathologist.
Inspect the Floor of the Mouth
The patient is asked to lift the tongue to the roof of the mouth, and the examiner inspects the floor of the mouth. Is there edema on the floor of the mouth? The opening of the submandibular gland, Wharton's duct, should be observed. The examiner should look for leukoplakia, erythroplakia, or a mass.
A ranula is a large mucous retention cyst on the floor of the mouth in association with submandibular and sublingual glands. The lesion is unilateral, painless, and bluish. It is lateral to the frenulum and is typically larger than a mucocele. As a ranula increases in size, there may be a reduction in tongue movement and difficulty in speech and swallowing. An example of a ranula is pictured in Figure 12-30.
Figure 12-30 Ranula.
Palpate the Floor of the Mouth
The floor of the mouth should be examined by bimanual palpation. This is performed by placing one finger under the tongue and another finger under the chin to assess any thickening or masses. Whenever palpating in a patient's mouth, the examiner should hold the patient's cheeks, as shown in Figure 12-31. This is done as a precaution in case the patient suddenly tries to speak or bite down on the examiner's finger. The examiner's right index finger is placed under the tongue; the left thumb and third finger are pushing the patient's cheeks inward to prevent biting; and the left index finger palpates under the patient's chin.
Inspect the Hard and Soft Palates
Inspect the rugae and vault shape of the palates. Also inspect the palates for ulceration and masses. Masses are usually minor salivary gland tumors, mostly malignant. Are any white plaques present? Is the soft palate edematous? Is the uvula in the midline?
Is the palate intact? Figure 12-32 shows a severe cleft palate. Clefts of the palate and lips are distinct entities but are closely related embryologically, functionally, and genetically. The incidence of an isolated cleft palate is 1 per 1000 births. Clefts of the palate vary widely in size and shape. They can extend from the soft palate, to the hard palate, and to the incisive foramen. Recurrent otitis media, hearing loss, and speech defects are frequent complications.
In patients with impaired immunity, or in those whose microbial flora has been altered by antibiotics, Candida albicans, a normal commensal organism of the gastrointestinal tract, can become highly invasive, as seen in Figure 12-33. The patient, who has AIDS, has pseudomembranous candidiasis of the palate and uvula.
Figure 12-31 A and B, Technique for palpating the floor of the mouth.
Figure 12-32 Cleft palate.
Figure 12-33 Pseudomembranous candidiasis.
Are petechiae present? Petechiae are commonly seen in association with infective endocarditis, leukemia, oral sex, and viral infections such as infectious mononucleosis. Fellatio can result in palatal petechiae, characteristically at the junction of the hard and soft palates, as pictured in Figure 12-34.
A common finding is a torus palatinus, which is a discrete, hard, lobulated swelling in the midline of the posterior portion of the hard palate. This benign lesion is an overgrowth of the palatine bone. It is painless and asymptomatic and occurs twice as often in women as in men. It may remain undetected until it interferes with the fit of a denture. More than 20% of the population have at least a small torus palatinus. Figure 12-35 shows tori palatini in two patients. Not uncommonly, individuals may have multiple tori palatini; Figure 12-36 shows a patient with three tori palatini. A torus mandibularis is a hard, bony, often bilateral swelling that protrudes from the lingual surface of the mandible at the level of the premolar teeth. It is much less common than a torus palatinus. About 5% to 10% of the population have a torus mandibularis; however, one fifth of mandibular tori are unilateral. Figure 12-37 shows bilateral mandibular tori in two patients.
Figure 12-38 shows a patient with early invasive erythroplakia (red plaque) of the palate.
Figure 12-34 Palatal petechiae.
Figure 12-35 A and B, Torus palatinus.
Inspect the Salivary Glands
The ductal orifices of the parotid gland and the submandibular gland should be visualized. The condition of the papillae should be inspected. Is there a flow of saliva? This is best evaluated by drying the papilla with a cotton applicator and observing the flow of saliva produced by exerting external pressure on the gland itself.
The salivary glands are usually not visible. Careful observation of the face determines any asymmetry that is due to unilateral salivary gland enlargement. Obstruction to flow or infiltration of the gland results in glandular enlargement. Figure 12-39 illustrates a patient with left parotid enlargement as a result of obstruction to flow by a stone.
Palpate the parotid and submandibular glands. Determine the consistency of each gland. Is tenderness present?
Inspect the Twelfth Cranial Nerve
Ask the patient to stick out the tongue. Does the tongue deviate to one side? A hypoglossal, or 12th cranial, nerve palsy does not allow the lingual muscles on the affected side to contract normally. Consequently, the contralateral side ''pushes'' the tongue to the side of the lesion.
Figure 12-36 Multiple tori palatini.
Figure 12-37 A and B, Bilateral mandibular tori.
The Pharynx
Inspect the Pharynx
Examination of the pharynx is limited to inspection. To visualize the palate and oropharynx adequately, the examiner usually must use a tongue depressor. The patient is asked to open the mouth widely, stick out the tongue, and breathe slowly through the mouth. On occasion, leaving the tongue in the floor of the mouth provides better visibility. The examiner should hold the tongue depressor in the right hand and a light source in the left. The tongue blade should be placed on the middle third of the tongue. The tongue is depressed and scooped forward behind the front teeth. The examiner should be careful not to press the patient's lower lip or tongue against the teeth with the tongue depressor. If the tongue depressor is placed too anteriorly, the posterior portion of the tongue will mound up, making inspection of the pharynx difficult; if placed too posteriorly, the gag reflex may be stimulated.
Is infection present? Is candidiasis present?
Figure 12-38 Erythroplakia of the palate.
Figure 12-39 Left parotid enlargement.
An accessory for the oto-ophthalmoscope handle is a light source that holds the tongue depressor and makes the examination easier. Both techniques of holding the tongue depressor are demonstrated in Figure 12-40.
Inspect the Tonsils
Evaluate tonsillar size. Tonsillar enlargement results from infection or tumor. In chronic tonsillar infection, the deep tonsillar crypts may contain cheeselike debris. Figure 12-41 shows enormous tonsillar enlargement, known as ''kissing tonsils.'' Figure 12-42 depicts massive tonsillar enlargement in a patient with infectious mononucleosis; the cheeselike deposit in the tonsillar crypts is visible.
Is a pseudomembranous patch or membrane present over the tonsils? A membrane is associated with acute tonsillitis, infectious mononucleosis, and diphtheria. Figure 12-43 shows the oral cavity, characterized by erythema and a gray, membranous exudate, in a patient with diphtheria.
Inspect the Posterior Pharyngeal Wall
Is there a discharge, mass, ulceration, or infection present? Ask the patient to say, ''Aahhh,'' as you observe for soft palate elevation.
Figure 12-40 A, Use of the tongue depressor to inspect the pharynx. B, Use of the tongue depressor attachment to inspect the oral pharynx.
Figure 12-41 ''Kissing tonsils.'' Notice the tonsillar crypts.
Figure 12-42 Infectious mononucleosis. Note the massive tonsillar enlargement and the cheeselike substance in the crypts.
Figure 12-43 Pseudomembrane secondary to diphtheria.
Figure 12-44 Mirror laryngoscopy. A, Proper technique for holding the tongue and placement of the mirror. B, Cross-sectional view through the pharynx, illustrating placement of the mirror. C, Mirror reflection of the vocal cords.
Inspect the Gag Reflex
At the end of the inspection, tell the patient that you are now going to test the gag reflex. The tip of the tongue depressor should gently touch the posterior surface of the tongue or the posterior pharyngeal wall. The gag reflex should follow rapidly.
The Larynx
Using the Laryngeal Mirror
The tongue is held while a small, slightly warmed mirror is introduced into the mouth. The mirror should not be excessively warm and should avoid contact with the tongue. The patient is asked to breathe normally through the mouth. The mirror should be pushed upward against the uvula and positioned in the oropharynx. A beam of light can then be reflected off the mirror onto the internal laryngeal structures. This technique is demonstrated in Figure 12-44.
Although the examination of the larynx is important, indirect laryngoscopy is usually performed only by specialists. Any patient exhibiting symptoms of laryngeal disease should certainly be evaluated further.
Clinicopathologic Correlations
Lesions of the oral cavity are common. The most common acute oral ulcer is the traumatic ulcer; the aphthous ulcer, or canker sore, is the next most common. Traumatic and aphthous lesions vary widely in size, although the latter are usually less than 1 cm in diameter. Both are relatively superficial with raised borders. Aphthous ulcers are usually located on the loose buccal or labial mucosa, whereas traumatic ulcers can occur anywhere. Despite the small size of many of these ulcers, they can be extremely painful. In addition, aphthous ulcers may recur in many patients. Both types of ulcers usually heal within 2 to 3 weeks without scarring. A solitary, or giant, aphthous ulcer of the palate is shown in Figure 12-45. The patient has periadenitis mucosa necrotica recurrens, also known as major aphthous ulcer. These lesions are larger than multiple aphthous ulcers and start as submucosal lesions that break down to form ulcers that may persist for many weeks before healing by secondary intention. Any part of the oropharynx may be affected, but the tonsils and soft palate are the most common sites.
Figure 12-45 Solitary aphthous ulcer.
Acute multiple ulcers that are preceded by or associated with vesicles may have infective or immunologic causes. Primary herpes simplex, herpes zoster, coxsackievirus, and HIV are causative infective agents. Allergic stomatitis, benign mucous membrane pemphigoid, pemphigus vulgaris, Behcet's disease, and erythema multiforme are common immunologic causes. Radiation therapy or chemotherapy may predispose an individual to the development of acute multiple ulcers.
Benign mucous membrane pemphigoid, or cicatricial pemphigoid, is a chronic mucocutaneous bullous disease of elderly people in which the lesions are commonly limited to the oral cavity and conjunctiva. Subepidermal bullae, up to 2 cm in size, and autoantibodies to the basement membrane are present; erosion may be present as well. Skin involvement is rare and usually not severe. Nikolsky's sign, in which the bulla or external layer of mucous membrane or skin is easily separated from the underlying tissue by slight friction, is usually positive. Figure 12-46 depictds benign mucous membrane pemphigoid. Note the denudation of the gingivae. Figure 12-47 depicts cicatricial pemphigoid. The most common oral finding is patchy, desquamative gingivitis, as seen in this figure.
Pemphigus vulgaris affects the oral cavity in 75% of cases. Autoantibodies to the epithelial intercellular substance are present. Nikolsky's sign is negative. The lesions are almost always painful. Figure 12-48 depicts pemphigus vulgaris; the desquamative gingivitis is visible. Another case of pemphigus vulgaris is seen in Figure 12-49. Note the large and confluent ulcerations, which were painful, on the soft palate.
Figure 12-46 Benign mucous membrane pemphigoid.
Figure 12-47 Cicatricial pemphigoid.
Large chronic single ulcers may result from fungal infections such as aspergillosis or histoplasmosis. Infections by herpes simplex virus, cytomegalovirus, Mycobacterium organisms (which cause tuberculosis), and Treponema pallidum (which causes syphilis) are also well-known causes of this type of ulcer. Immunologic disorders such as pemphigus, systemic lupus erythematosus, bullous pemphigoid, and erosive lichen planus are often the cause of chronic multiple ulcers.
Cancer of the oral cavity is common. Carcinoma of the lip accounts for 30% of all cancers in this area and approximately 0.6% of all cancers. Most of these malignant tumors are squamous cell carcinomas. The lower lip is the site most frequently involved (95%). The patients are usually 50 to 70 years of age, with a strong male predominance (95%). Squamous cell carcinoma is characterized by a hard, infiltrative, usually painless ulcer. The risk factors that predispose to squamous cell carcinoma of the oral cavity are the same as for leukoplakia: smoking, spirits (alcohol), spices, syphilis, and spikes (ill-fitting dentures)—the ''five Ss.'' Figure 12-50 depicts a squamous cell carcinoma of the lower lip.
As mentioned earlier in this chapter, risk factors for oral cancers include tobacco use, alcohol consumption, and chewing betel nuts. Betel nuts are actually seeds of the betel palm (Areca catechu). Betel nut chewing is a tradition that dates back thousands of years. The nuts are chewed for their mildly euphoric stimulant effect, attributed to the presence of relatively high levels of psychoactive alkaloids. Chewing betel nuts increases the capacity to work, creates a warm sensation in the body, heightens alertness, and increases sweating. Although betel nut chewing is a part of many Asian and Pacific cultures and often takes place at ceremonies and gatherings, betel nuts are often sold at roadside booths decorated with multicolored neon lights for taxi and truck drivers to keep them awake. The International Agency for Research on Cancer (IARC) regards the betel nut as a known human carcinogen. In Asian countries and communities where betel nuts are consumed extensively, oral cancer accounts for up to 50% of all malignant cancers. Betel nut chewers in Taiwan were found to have a risk of acquiring oral cancer 28 times higher than that of nonusers, and people who chew betel nuts, smoke cigarettes, and drink alcohol are 123 times more likely to develop oral cancer. In 2006 in Taiwan, it was estimated that the government spent at least NT$5 billion (US$151 million) to cover medical expenses for betel nut-related diseases. Figure 12-51A shows the mouth of a patient from Taiwan with a long-standing habit of betel nut chewing; note the red stain on his teeth. Figure 12-51B shows a betel nut wrapped in its leaf.
Figure 12-48 Pemphigus vulgaris.
Figure 12-49 Pemphigus vulgaris.
In addition to these risk factors, biologic factors include viruses and fungi, which have been found in association with oral cancers. The human papillomavirus (HPV), particularly strains HPV16 and HPV18, has been implicated in some oral cancers. HPV is a common sexually transmitted virus that infects about 40 million Americans. There are more than 80 strains of HPV, most thought to be harmless. However, 1% of persons infected have the HPV16 strain, which is a causative agent in cervical cancer and now is linked to oral cancer as well. Another possible risk factor for oral cancer is lichen planus, an inflammatory disease of the oral soft tissues.
Lingual carcinoma is often easily missed because, in its early stages, it is usually painless. In 2007, it was estimated that there were 9800 new cases of lingual cancer. It occurs on the lateral aspects of the tongue or on its undersurface; there is commonly extension onto the tongue from a lesion on the floor of the mouth. Figure 12-52 depicts a carcinoma of the right lateral border of the tongue. Figure 12-53 depicts squamous cell carcinoma of the right lateral border of the tongue in another patient, with extension on the floor of the mouth.
Carcinoma of the floor of the mouth accounts for 10% to 15% of all oral cancers and is the most common site of oral cancer in African Americans. In 2007, it was estimated that there were 10,660 new cases of floor of the mouth cancer. It occurs primarily in men at an average age of 65 years. Approximately 20% of patients with carcinoma of the floor of the mouth have a second primary tumor. It is particularly important to examine the area behind the last molar tooth and the associated floor of the mouth and base of the tongue. Figure 12-54 shows a squamous cell carcinoma of the floor of the mouth.
Figure 12-50 Squamous cell carcinoma of the lower lip.
Figure 12-51 A, Red staining of teeth in a betel nut user. B, Betel nut wrapped in its leaf.
Figure 12-52 Squamous cell carcinoma of the tongue.
Figure 12-53 Squamous cell carcinoma of the tongue and floor of the mouth.
Figure 12-54 Squamous cell carcinoma of the floor of the mouth.
Salivary gland neoplasms are not uncommon. They occur with an annual incidence of 6 per 100,000 individuals. More than 70% occur in the parotid gland. There are more than 50 types of salivary gland tumors. The most common salivary gland tumor (65%) is the pleomorphic adenoma, and 20% of these mixed-cell tumors are malignant. Tumors of the submandibular gland are much less frequent, but 40% are malignant. Sublingual gland tumors are rare but usually malignant.
Herpetic gingivostomatitis is infection of the gums and oral mucosa by herpes simplex virus. Small vesicles form on the oral mucous membrane and rapidly break down into painful ulcers on an intensely erythematous base. Figure 12-55 depicts herpetic gingivostomatitis; the multiple erosions and marginal gingivitis are apparent. Figure 12-56 shows herpetic lesions on the palate with ulceration.
Acute necrotizing gingivostomatitis (also known as ulcerative gingivostomatitis or Vincent's gingivitis), is a severe, noncommunicable disease of young adults resulting from infection by Fusobacterium nucleatum or Borrelia vincentii. Most cases occur suddenly in the spring or autumn. The patients, commonly men with poor oral hygiene, present with gingival bleeding, alteration of taste, gingival pain, malaise, fever, and halitosis. As the disease progresses, a whitish pseudomembrane develops along the gingival margins, with ulceration and blunting of the interdental papillae. Acute necrotizing gingivitis, pictured in Figure 12-57, may be an early feature of HIV infection.
Figure 12-55 Herpetic gingivostomatitis.
Figure 12-56 Herpetic lesions on the palate.
Figure 12-57 Acute necrotizing gingivostomatitis.
On August 6, 2008, the Centers for Disease Control and Prevention (CDC) released a new estimate of the annual number of new HIV infections (HIV incidence) in the United States, revealing that the HIV epidemic is worse than previously thought. That estimate indicated that approximately 56,300 people were newly infected with HIV in the United States in 2006, which is higher than the CDC's previous estimate of 40,000. The new estimate also confirmed that gay and bisexual men of all races, African Americans, and Hispanics/Latinos were most heavily affected by HIV. Although first observed in men having sex with men, HIV is now spreading among the heterosexual population. These cases are related to the use of illegal drugs and contaminated needles, prostitution, and unprotected sex. It has been estimated that more than 90% of patients infected with HIV will have at least one oral manifestation of their disease. It appears that as further immunologic impairment develops, the risk of oral lesions increases. It has also been shown that the oral manifestations can be used as a marker of immune compromise, which is independent of the CD4+ T-lymphocyte count. If left untreated, the oral lesions may interfere with chewing, swallowing, and talking. Many patients have such severe pain that they reduce their oral intake, which results in additional weight loss, malnutrition, and further wasting.
A common oral manifestation of HIV infection is angular cheilitis, also known as perleche. This painful condition is characterized by macerated, fissured, eroded, encrusted, whitish (occasionally erythematous) lesions in the corners of the mouth. Accumulations of saliva gather in the skin folds and are subsequently colonized by yeast organisms such as C. albicans. Angular cheilitis may be associated with intraoral candidiasis. Angular cheilitis may also develop in patients with normal immunity who wear ill-fitting dentures or wear dentures during the night. An example of angular cheilitis is pictured in Figure 12-58.
Figure 12-58 Angular cheilitis.
Figures 12-26 and 12-33 show patients with oral candidiasis, another extremely common condition associated with HIV infection. Oral candidiasis is characterized by chronic severe pain in the throat that worsens on swallowing or eating. The curdlike white plaques are soft and friable and can easily be wiped off, leaving an area of intensely erythematous mucosa.
Figure 12-27 shows a patient with oral hairy leukoplakia. As mentioned previously, this lesion is seen most frequently either unilaterally or bilaterally on the lateral margins of the tongue. The lesion is white, does not rub off, and occasionally occurs elsewhere in the mouth and oropharynx. Although not correlated with the stage of HIV infection, oral hairy leukoplakia may be the first sign of infection. It is seen most commonly in gay and bisexual men infected with HIV. It has been suggested that the Epstein-Barr virus may be a cofactor in the development of oral hairy leukoplakia. The finding of oral hairy leukoplakia mandates HIV testing.
As discussed in Chapter 8, The Skin, the oral lesions of Kaposi's sarcoma are common. Figure 8-93 shows some of the typical oral lesions. Lesions of Kaposi's sarcoma of the tongue (Fig. 12-59) and the hard palate (Fig. 12-60) are frequently found in patients with AIDS.
Figure 12-59 Kaposi's sarcoma of the tongue.
Table 12-1 summarizes the important signs and symptoms of some of the more common oral lesions. Table 12-2 reviews the most common oral lesions seen during the stages of HIV infection. Table 24-5 lists the chronology of dentition.
Figure 12-60 Kaposi's sarcoma of the hard palate.
Table 12-1 Symptoms and Signs of Oral Lesions
|
Lesion |
Symptoms |
Signs |
Other Information |
|
Aphthous ulcer (canker sore; see Fig. 12-45) |
Painful, recurrent white sore with red border on lips, inner side of cheeks, tip and sides of tongue, or palate |
Single lesion 0.5-2 cm in diameter that is first maculopapular but then ulcerates and has an area of erythema at its border; lesions usually on movable mucosal areas |
Sixty percent of population have periodic canker sores lasting up to 2 weeks; cause is unknown |
|
Herpetic ulcer (cold sore; fever blister; see Figs. 12-10, 12-55, 12-56) |
Painful, recurrent sores on the lips |
Multiple vesicles, papules, or ulcers on the mucocutaneous junction, hard palate, or gingivae; as the bullae break, crusting occurs |
Primary herpetic infection in children: multiple lesions in clusters on fixed mucous membranes; small, discrete, whitish vesicles before ulceration; ulcers about 1 mm in diameter, which may coalesce; tender lymphadenopathy, fever, and malaise present Recurrent form, common in adults: lip lesions Both forms: self-limited illness, 1-2 weeks |
|
Chancre |
Painless sore on lips or tongue lasting 2 weeks to 3 months |
Single ulcerated lesion with indurated border; lesion without central necrotic material; tender lymphadenitis may be present |
Examiner should look for genital lesions (see Figs. 18-13 and 19-33) |
|
Squamous cell carcinoma (see Figs. 12-28, 12-50, and 12-52 to 12-54) |
Ulcerated sore of the lips, floor of mouth, or tongue (especially lateral borders); erythroplakia of floor of mouth, soft palate |
Single indurated lesion with indurated and raised border; often in an area of leukoplakia or erythroplakia; absence of necrotic material in crater; base often erythematous; speech alterations may result if lesion is large; painless lymphadenopathy may be present |
Frequently in alcoholic patients or smokers |
|
Erythema multiforme |
Sudden onset of multiple painful ulcers in mouth of lips |
Hemorrhagic areas of ulceration with erythematous bases, often with pseudomembrane; lesions start as bullae; skin involvement common (target lesions) |
Many precipitating factors include drug reactions, herpesvirus infections, endocrine changes, and an underlying malignancy; most common in winter and spring in young adults; frequently recurring |
|
Denture hyperplasia |
Painless excess tissue at border of denture |
Spongy, redundant, often erythematous tissue with impression of edge of denture; frequently seen on anterior maxillary mucosa |
|
|
Candidiasis (moniliasis; thrush; see Figs. 12-26, 12-33) |
Burning sensation in areas of tongue, inside of cheek, or throat |
Whitish pseudomembrane, resembling milk curd, that can be peeled off, leaving a raw, erythematous area that may bleed; erythematous variant is secondary to broad- spectrum antibiotics |
Often seen in individuals who are chronically debilitated, patients who are immunosuppressed, or patients receiving long-term antibiotic therapy; commonly seen in persons with AIDS |
Continued
Table 12-1 Symptoms and Signs of Oral Lesions—cont'd
|
Lesion |
Symptoms |
Signs |
Other Information |
|
Erythroplakia (see Figs. 12-20, 12-38) |
Painless red area on inside of cheek, tongue, or floor of mouth |
Granular, erythematous papules that bleed |
High potential for malignancy |
|
Leukoplakia (see Figs. 12-16, 12-17, 12-27) |
Painless white area on inside of cheek, tongue, lower lip, or floor of mouth |
Hyperkeratinized, whitish lesion that cannot be scraped off; looks similar to flaking white paint; often speckled with reddish areas; associated adenopathy may indicate malignant changes of lesion |
Patients are usually men over 40 years of age; linked to smoking, AIDS, alcoholism, and chewing tobacco |
|
Lipoma (see Fig. 12-24) |
Slow-growing, painless mass on inner surface of cheek or tongue |
Yellowish, nontender, soft mass; freely mobile |
|
|
Lichen planus (see Fig. 12-15) |
Usually no symptoms; erosive form causes painful, burning sores of inner side of cheek or tongue |
White lesions on buccal mucosa bilaterally in the form of reticulated papules in lacelike pattern; erosive form appears as hemorrhagic ulcerated lesion with possible white areas or bullae; pseudomembrane may be present over lesion |
Nonerosive form is a common cause of white lesions in the mouth; skin involvement in 10%-35% of affected patients and more frequently seen in patients with emotional stress |
|
Traumatic ulcer |
Pain in an area of a sore; short duration (1-2 weeks) |
Single lesion with raised erythema at its border; center often with necrotic debris; occasionally purulent; mild lymphadenitis may be present |
Patient frequently know the cause (e.g., biting cheek while eating) |
|
Mucocele (see Fig. 12-13) |
Intermittent, painless swelling of the lower lip or inside of cheek; slightly bluish; occasionally ruptures |
Dome-shaped, 1-2 cm in diameter, freely mobile cystic lesion |
Related to trauma to ductal system of minor labial salivary glands |
|
Black hairy tongue (see Fig. 12-25B) |
Gagging sensation associated with ''hairy'' sensation of tongue; large brown or blackish painless lesion on top of tongue |
Elongation of filiform papillae on the dorsum of tongue with a change in their color to almost black or brown |
History of excessive antibiotic use, excessive use of mouthwash, poor oral hygiene, smoking, or alcohol use is common |
|
Fordyce's spots (see Fig. 12-18) |
None |
Clusters of small, yellowish, raised lesions best seen on the buccal mucosa opposite the molar teeth |
Common in older individuals; they are normal, hyperplastic sebaceous glands |
|
AIDS, acquired immunodeficiency syndrome. |
|||
Table 12-2 Occurrence of Oral Lesions During the Stages of HIV Infection
|
Oral Lesion |
Occurrence Durin Primary HIV Infection |
g Occurrence During Early HIV Disease* |
r Advanced HIV Disease{ |
|
Candidiasis (see Figs. 12-26, 12-33) |
Common |
Occasional |
Very common |
|
Oral hairy leukoplakia (see Fig. 12-27) |
No |
Occasional |
Very common |
|
Kaposi's sarcoma (see Figs. 8-93, 12-59, 12-60) |
No |
Rare |
Very common |
|
Linear gingival erythema |
No |
Common |
Very common |
|
Acute necrotizing gingivitis (see Fig. 12-57) |
No |
Rare |
Common |
|
Necrotizing stomatitis |
No |
No |
Common |
|
Herpes simplex- related (see Figs. 12-10, 12-55, 12-56) |
No |
Occasional |
Common |
|
Aphthous ulcers (see Fig. 12-45) |
Common |
Occasional |
Very common |
HIV, human immunodeficiency virus.
*CD4+ count > 500 cells/mm3.
*CD4+ count < 200 cells/mm3.
Adapted from Weinert M, Grimes RM, Lynch DP: Oral manifestations of HIV infection. Ann Intern Med 125:485, 1996.
Useful Vocabulary
Listed here are the specific roots that are important to understand the terminology related to diseases of the mouth and pharynx.
|
Root |
Pertaining to |
Example |
Definition |
|
arytenoid- |
pitcher-shaped structure |
arytenoiditis |
Inflammation of the arytenoid cartilage |
|
bucco- |
cheek |
buccopharyngeal |
Pertaining to the cheek and pharynx |
|
cheil(o)- |
lip |
cheilitis |
Inflammation of the lip |
|
dent- |
tooth |
dental |
Pertaining to the teeth |
|
gingiv- |
gingiva(e) |
gingivectomy |
Surgical excision of diseased gingiva(e) |
|
gloss(o)- |
tongue |
glossoplegia |
Paralysis of the tongue |
|
-labi- |
lips |
nasolabial |
Pertaining to the nose and lip |
|
leuko- |
white |
leukoplakia |
White patch on mucous membrane; often premalignant |
Continued
|
linguo- |
tongue |
linguopapillitis |
Painful ulcers around the papillae of the tongue |
|
-plakia |
patch |
erythroplakia |
Red patch on mucous membrane; often premalignant |
|
ptyal- |
saliva |
ptyalism |
Excessive salivation |
|
stoma- |
mouth; opening |
stomatitis |
Inflammation of the mouth |
Writing Up the Physical Examination
Listed here are examples of the write-up for the examinations of the oral cavity and pharynx.
• The lips appear normal. The mucosa of the oral cavity is red and without masses, leukoplakia, or other lesions. There is good dentition and good dental hygiene. The tongue is midline and does not deviate to either side. The tonsils are absent. The pharynx appears normal. The palate is normal, without ulcers or masses.
• There is a 1- to 2-cm, painful vesicular lesion at the mucocutaneous junction on the right side of the mouth. There is tonsillar hypertrophy with a purulent discharge in the crypts of both tonsils. There is bilateral anterior triangle lym- phadenopathy, greater on the right. The remainder of the examination of the oral cavity is unremarkable.
• There is a whitish pseudomembrane over the hard and soft palates, as well as over the tongue. When it is lifted, its erythematous base is friable and bleeds. The rest of the mouth and throat appears normal.
• The lateral border of the tongue has an ulcerated, indurated lesion, 2 x 1 cm.
• The palate has a dome-shaped 3-cm mass to the right of midline. Biopsy is recommended.
Bibliography
Aronson AE: Clinical Voice Disorders: An Interdisciplinary Approach. New York, Thieme-Stratton, 1980.
Benjamin B, Bingham B, Hawke M, et al: A Color Atlas of Otorhinolaryngology. Philadelphia, JB Lippincott, 1995.
Bingham BJG, Hawke M, Kwok P, et al: Atlas of Clinical Otolaryngology. St. Louis, Mosby-Year Book, 1992.
Cancer Facts & Figures. Atlanta, American Cancer Society, 2007.
Centers for Disease Control: Subpopulation estimates from the HIV incidence surveillance system—United States, 2006. MMWR 57(36):985, 2008.
DeBoever EH, Loesche W: Assessing the contribution of anaerobic microflora of the tongue to oral mal- odor. J Am Dent Assoc 126:1384, 1995.
DevCan: Probability of developing or dying of cancer software, version 5.1. Statistical Research and Applications Branch, National Cancer Institute, 2003. Available at: http://srab.cancer.gov/devcan; accessed June 6, 2008.
Eisen D, Lynch DP: The Mouth: Diagnosis and Treatment. St. Louis, Mosby, 1998.
Gupta PC, Warnakulasuriya S: Global epidemiology of areca nut usage. Addict Biol 7:77, 2002.
Hall HI, Ruiguang S, Rhodes P, et al: Estimation of HIV incidence in the United States. JAMA 300:520, 2008.
Jemel A, Tiwari R, Murray T, et al: Cancer Statistics, 2004. CA Cancer J Clin 54:8, 2004.
Kirby AJ, MuAoz A, Detels R, et al: Thrush and fever as measures of immunocompetence in HIV-1-infected men. J Acquir Immune Defic Syndr 7:1242, 1994.
McCarthy GM: Host factors associated with HIV-related oral candidiasis. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 73:181, 1992.
McIsaac WJ, Kellner JD, Aufricht P, et al: Empirical validation of guidelines for the management of pharyngitis in children and adults. JAMA 291:1587, 2004.
Moore PS, Chang Y: Detection of herpesvirus-like DNA sequences in Kaposi's sarcoma in patients with and without HIV infection. N Engl J Med 332:1181, 1995.
Nielsen H, Bentsen KD, Hojtved L, et al: Oral candidiasis and immune status of HIV-infected patients. Pathol Med 23:140, 1994.
Neuner JM, McCarthy EP, Davis RB, et al: Diagnosis and management of adults with pharyngitis: A cost- effective analysis. Ann Intern Med 139:113, 2004.
Pinkham JR, Casamassimo PS, Fields HW Jr, et al (eds): Pediatric Dentistry: Infancy Through Adolescence, 3rd ed. Philadelphia, WB Saunders, 1999.
Rosenberg M: Clinical assessment of bad breath: Current concepts. J Am Dent Assoc 127:475, 1996.
Scully C, Laskaris G, Pindborg J, et al: Oral manifestations of HIV infection and their management: I. More common lesions. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 71:158, 1991.
Scully C, Laskaris G, Pindborg J, et al: Oral manifestations of HIV infection and their management: II. Less common lesions. Oral Surg Oral Med Oral Pathol Oral Radiol Endod 71:167, 1991.
Silverman S: Color Atlas of Oral Manifestations of AIDS, 2nd ed. St. Louis, Mosby-Year Book, 1996.
Speilman AL, Bivona P, Rifkin BR: Halitosis: A common oral problem. N Y State Dent J 62:36, 1996.
Tonzetich J: Production and origin of oral malodor: A review of mechanisms and methods of analysis. J Periodontol 48:13, 1977.
Vincent MT, Celestin N, Hussain AN: Pharyngitis. Am Fam Physician 69:1465, 2004.
Warnakulasuriya S, Trivedy C, Peters TJ: Areca nut use: An independent risk factor for oral cancer. BMJ 324:799, 2002.
Weinert M, Grimes RM, Lynch DP: Oral manifestations of HIV infection. Ann Intern Med 125:485, 1996.
Wu MT, Lee YC, Chen CJ, et al: Risk of betel chewing for oesophageal cancer in Taiwan. Br J Cancer 85:658, 2001.
